Technicians use blueprints to install, maintain, troubleshoot, and service plant machinery and equipment. BA02: Blueprint Reading features skills-based curriculum delivered through LearnMate, Intelitek’s innovative e-learning platform. Through virtual activities, students learn all aspects of reading and interpreting blueprints in industrial environments.

JobMaster® trainees can be confident they will posess the skills needed for success in industrial maintenance careers!

Course Outline

    • Identifying Lines and their Functions
    • Single, Multiple and Auxiliary View
    • Reading and Locating Blueprint Dimensions
    • Determining Tolerances
    • Identifying Thread Dimensions
    • Identifying Tapers and Machine Surfaces
    • Cutting Plane and Sections
    • Geometric Dimensioning, Wear Limits and Assembly Drawings
    • Identifying Welding Symbols
    • Reading Plot Plans
    • Reading Footing, Foundation and Floor Plans
    • Reading Reinforced Concrete and Structural Steel Prints

Data Sheet

Click here to download a pdf data sheet.


This course is a component of the Foundations of Manufacturing series and the Advanced Foundations of Manufacturing series.

The online training can be used individually to augment an existing curriculum program or as a series to provide students fundamental and broad understanding of the manufacturing world.
